Yaesu FT-900 Transceiver

Manufacturer:

Model:

FT-900

Date:

1994

Category:

Group:

Description:

Information

Your FT-900 is a high-performance Transceiver providing up to 100 watts Transmitter output power on all HF amateur radio bands in CW, SSB and FM modes, and up to 25 watts carrier in AM. The Receiver tunes all frequencies between 100 kHz and 30 MHz in 2.5-Hz steps.

For mobile operation, a new lightweight detachable sub-panel permits separating the Transceiver and mounting the rear main unit in a remote location, keeping the most-commonly used front panel controls and display where you need them-in a comfortable, safe location (YSK-900 Separation Kit required for separate installation). This makes the FT-900 convenient for mobile and maritime amateur operation, or wherever space is critical.

Operating frequency and other important settings are displayed on a high-contrast backlit LCD. The new three-mode bargraph meter display features delayed “peak hold” circuitry for the tuning bargraph segments that simplifies tuning stations with rapidly varying signal strength. The new flexible mounting scheme combined with the famous high-performance circuitry of the earlier FT-890 is combined to form a compact, reliable rig that is ideally suited for base or mobile operation.

CW enthusiasts will enjoy the new CW reverse-sideband, which lets you switch the Receiver carrier point (offset) to help sidestep QRM, and not have toretune stations when switching between LSB and CW (convenient when working on 40 meters and below). If you use a multi-mode TNC or CW decoder, the adjustable BFO offset lets you match the CW pitch to that used by your unit so that the tuned station will be centered in the Receiver IF passband, and your decoder will give optimum copy. The FT-900 full-featured internal electronic keyer allows front panel control of keying speed, weighting and mode (semi-/full break-in).

Modern circuit design employs surface-mount components on composite epoxy boards for high reliability and serviceability. Twin direct-digital synthesizers (DDSs) and a magnetic rotary encoder with selectable 2.5-, 5- or 10-Hz tuning steps provide silent, silky-smooth tuning, pure local signals and very fast tx/rx changeover important when operating QSK CW. Frequency accuracy and stability are assured by driving both DDSs from a single master oscillator, and the optional TCXO-3 temperature-compensated crystal Oscillator is available for enhanced ±2-ppm stability from 0° ~ +50° C.

The low-noise, high performance Receiver front end uses parallel high-IDSS FETs in a constant-gain, grounded-gate RF amplifier, feeding an active double balanced quad FET-ring mixer. The RF Amplifier can be bypassed for direct-feed to the mixer (by the IPO button), and a 12-dB attenuator can be inserted for clear copy of even very strong signals.

Interference rejection is facilitated by the unique «up-down» conversion scheme, and includes an IF shift and notch circuit. The optional XF-110S crystal filter can be installed for enhanced SSB and AM nar-row-skirt selectivity.

Four microprocessors in the FT-900 are programmed to provide the simplest possible control interface for the operator. Two independent (A/B) VFOs for each band (20 total) hold their own frequencies and modes settings. One hundred memories store all of this data for both VFOs, giving a total of 220 independent sets of frequency, mode and other selections.
Flexible scanning features allow all 100 memories or only those selected to be freely-tuned and scanned. In addition, ten special memories also let you limit the tuning/scanning range between their stored frequencies. Scan resume mode is selectable between timed or carrier-delay, and scanning speed is also adjustable.

Other valuable features include an effective noise blanker, all-mode squelch, multi-function meter, and an AF speech processor with adjustable IF offset which lets you increase the average power of your SSB signal and allows tailoring audio response to your voice characteristics. The FT-900 weighs under 5.5 kg and an internal thermally-switched fan allows full Transmitter output without any rear panel protrusions, giving easy access to rear panel controls and connectors.

A choice of automatic Antenna tuners is available for the FT-900, each with its own microprocessor and 31 memories which store most recent Antenna matching settings for nearly instant recall while changing operating frequency. The ATU-2 can be mounted inside the transceiver, while the FC-800 can be installed remotely at the Antenna feedpoint. Each Antenna Tuner is controlled from the front panel of the FT-900.

The MH-31a8J hand microphone is supplied with FT-900. Other accessories include the FP-800 AC Power Supply with Loudspeaker; the SP-6 External Loudspeaker with audio filters and optional LL-5 Phone Patch and the MMB-20 Mobile Mounting Bracket.

Before connecting the power cord, you should read the Installation section carefully, heeding the warnings in that section to avoid damage to the set. After installation, please take time to work through the Operation chapter, referring to the fold-out panel diagrams at the back of the manual as necessary for details. This manual is intended to be read while sitting down in front of the FT-900, so you can try out each control and feature as they are described.

show more

Service Manual

Manual Type:

Service Manual

Pages:

173

Size:

27.52 Mbytes (28861222 Bytes)

Language:

english

Revision:

Manual-ID:

Date:

Quality:

Scanned document, all readable.

Upload date:

2014 07 27

MD5:

1fd0c23b4b3d68a4141299402f495c92

Downloads:

3159

Information

Introduction & Chip Component Replacement … 1

Specifications … 1-2

Circuit Board Access, Battery Replacement and CPU
Resetting … 2

Alignment … 3

Circuit Description … 4

Block & Interconnection Diagrams … 5

PCB Diagrams & Parts Lists … 6

Local Unit … 6A

RF Unit, Notch
Unit … 6B

Control (CNTL)-l Unit … 6C ^

Power Amp (PA) Unit … 6D

LPF Unit … 6E

CAR-DDSUnit … 6F

SUB-DDS
Unit … 6G

Control (CNTL)-2 Unit … 6H

BLUnit … 61

SWUnit … 6J

VR, MIC Unit … 6K

CONNECT-1/-2, SPJ Unit … 6L

Mechanical Details (Exploded Views & Mechanical
Parts) … 7

Accessory & Options (parts)

ATU-2 Automatic Antenna Tuner
(option) … 8A-1

MH-31A8J Hand-Held Microphone (accessory) … 8B

This manual provides technical information necessary for
servicing the Yaesu FT-900 HF Transceiver. It does not
include information on specifications, installation and
operation, which are described in the FT-900 Operating
Manual, provided with each transceiver, or on FT-900
accessories, which are described in manuals provided with each.

Servicing this equipment requires expertise in handling
surface mount chip components. Attempts by non-qualified
persons to service this equipment may result in permanent
damage not covered by warranty. For the major circuit
boards, each side of the board is identified by the type of
the majority of components installed on that side. In most
cases one side has
only chip components, and the other has either a mixture of
both chip and lead components (trimmers, coils, electrolytic
capacitors, packaged ICs, etc.), or lead components only.

show more

User Manual

Manual Type:

User Manual

Pages:

51

Size:

3.44 Mbytes (3609832 Bytes)

Language:

french

Revision:

Manual-ID:

Date:

Quality:

Scanned document, reading partly badly, partly not readable.

Upload date:

2020 01 11

MD5:

5e2d42ab9d5d1ec2e65195e31adb8c5c

Downloads:

445

Information

Description générale … 1

Spécifications … 3
Accessoires & Options … 4
Installation de la station … 7
Vérifications préliminaires 7
Installation de la face avant 7
Alimentation secteur 8
Emplacement du transceiver 8
Mise à la terre 8
Inclinaison de la face avant 8
A propos de l’antenne 8
Alimentation en mobile 9
Montage en mobile 9
Face avant séparée 9
Installation d’une antenne mobile 9
Interconnexion des accessoires 9
Sauvegarde de la mémoire 9
Branchement ent des accessoires externes 10
Brochage des connecteurs 11
Connexion d’un amplificateur linéaire 12
Personalisation des commandes &
Cominaisons de touches 13
Fonctionnement … 15
Guide pour bien commencer … 15

Utilisation du clavier 16
Fonctions de l’appareil de mesures 17
Réception à couverture générale 17
17
Lutter contre les interférences …

Sélections sur l’étage d’entrée
Préamplificateur (IPO) et ATTénuateur 18
Réglage de l’AGC 18

Réglage du Noise Blanker 18
Réglage de l’IF-shift 18

Filtres Fl AM et CW étroits 18
Filtre Notch FI 19
Emission … 20
Accord automatique d’antenne 20
Emission SSB 20
Séiection de ia tonalité du micro 21
Compresseur BF (Speech processor) 21
VOX (commande E/R par la voix) 21
Emission CW … 22
Fonctionnement avec manipulateur droit 22
Utilisation du manipulateur électronique
interne 23

Utilisation d’un manipulateur électronique
externe 23
Tonalité de la CW (Pitch) 23
Bande latérale CW inverse 33
Emission en AM … 24
Emission en FM … 24
Fonctionnement sur ies répéteurs FM 2 b
Clarifier (Décalage en réception) 35
VFO-B et fonctionnement en SPLIT . 26
Caractéristiques des mémoires … 26
Mise en mémoire 7
Vérification des contenus mémoires 28
Rappel de mémoire et fonctionnement 28
Le scanning 29
Reprise du scanning 29
Saut de mémoires pendant le scanning 30
Masquage de mémoire 30
Scanning PMS Mémoires
spéciales, P1 à PO 30
Copies entre mémoires 31
Réglage de la vitesse
de scanning des VFO 31
Les modes digitaux … . . . 3?
Interconnexions avec un TUATNC 32
Réglages du transceiver 33
Affichage de fréquence et accord 33
Packet FM à 1200 baud 34
Interférences produites par l’ordinateur 34
Installation des accessoires

internes … . . 37

Dépose du capot supérieur

TCXO-3 37
Oscillateur à très haute stabilité
38
Filtres à quartz optionnels
Installation du coupleur ATU-2 38

CAT : Système de commande par
ordinateur … . 43
Protocole CAT 44
Données renvoyées par ie FT-900 44
Sélection donnée Status Update 46
Exemples de programmation 47
Annexes
Panneau avant … Dépliant

Panneau arriéré … Dépliant
Affichage & Bargraph … Dépliant

show more

User Manual

Manual Type:

User Manual

Pages:

73

Size:

9.26 Mbytes (9709229 Bytes)

Language:

english

Revision:

Manual-ID:

Date:

1994 01 01

Quality:

Scanned document, all readable.

Upload date:

2020 03 16

MD5:

65df5dee7d31780729340bb58f0a5103

Downloads:

400

Yaesu FT-900 Приемопередатчик

Производитель:

Модель:

FT-900

Дата:

1994

Категория:

Группа:

Описание:

Информация

Your FT-900 is a high-performance Transceiver providing up to 100 watts Transmitter output power on all HF amateur radio bands in CW, SSB and FM modes, and up to 25 watts carrier in AM. The Receiver tunes all frequencies between 100 kHz and 30 MHz in 2.5-Hz steps.

For mobile operation, a new lightweight detachable sub-panel permits separating the Transceiver and mounting the rear main unit in a remote location, keeping the most-commonly used front panel controls and display where you need them-in a comfortable, safe location (YSK-900 Separation Kit required for separate installation). This makes the FT-900 convenient for mobile and maritime amateur operation, or wherever space is critical.

Operating frequency and other important settings are displayed on a high-contrast backlit LCD. The new three-mode bargraph meter display features delayed “peak hold” circuitry for the tuning bargraph segments that simplifies tuning stations with rapidly varying signal strength. The new flexible mounting scheme combined with the famous high-performance circuitry of the earlier FT-890 is combined to form a compact, reliable rig that is ideally suited for base or mobile operation.

CW enthusiasts will enjoy the new CW reverse-sideband, which lets you switch the Receiver carrier point (offset) to help sidestep QRM, and not have toretune stations when switching between LSB and CW (convenient when working on 40 meters and below). If you use a multi-mode TNC or CW decoder, the adjustable BFO offset lets you match the CW pitch to that used by your unit so that the tuned station will be centered in the Receiver IF passband, and your decoder will give optimum copy. The FT-900 full-featured internal electronic keyer allows front panel control of keying speed, weighting and mode (semi-/full break-in).

Modern circuit design employs surface-mount components on composite epoxy boards for high reliability and serviceability. Twin direct-digital synthesizers (DDSs) and a magnetic rotary encoder with selectable 2.5-, 5- or 10-Hz tuning steps provide silent, silky-smooth tuning, pure local signals and very fast tx/rx changeover important when operating QSK CW. Frequency accuracy and stability are assured by driving both DDSs from a single master Oscillator, and the optional TCXO-3 temperature-compensated crystal Oscillator is available for enhanced ±2-ppm stability from 0° ~ +50° C.

The low-noise, high performance Receiver front end uses parallel high-IDSS FETs in a constant-gain, grounded-gate RF Amplifier, feeding an active double balanced quad FET-ring mixer. The RF Amplifier can be bypassed for direct-feed to the mixer (by the IPO button), and a 12-dB attenuator can be inserted for clear copy of even very strong signals.

Interference rejection is facilitated by the unique «up-down» conversion scheme, and includes an IF shift and notch circuit. The optional XF-110S crystal filter can be installed for enhanced SSB and AM nar-row-skirt selectivity.

Four microprocessors in the FT-900 are programmed to provide the simplest possible control interface for the operator. Two independent (A/B) VFOs for each band (20 total) hold their own frequencies and modes settings. One hundred memories store all of this data for both VFOs, giving a total of 220 independent sets of frequency, mode and other selections.
Flexible scanning features allow all 100 memories or only those selected to be freely-tuned and scanned. In addition, ten special memories also let you limit the tuning/scanning range between their stored frequencies. Scan resume mode is selectable between timed or carrier-delay, and scanning speed is also adjustable.

Other valuable features include an effective noise blanker, all-mode squelch, multi-function meter, and an AF speech processor with adjustable IF offset which lets you increase the average power of your SSB signal and allows tailoring audio response to your voice characteristics. The FT-900 weighs under 5.5 kg and an internal thermally-switched fan allows full Transmitter output without any rear panel protrusions, giving easy access to rear panel controls and connectors.

A choice of automatic Antenna tuners is available for the FT-900
each with its own microprocessor and 31 memories which store most recent Antenna matching settings for nearly instant recall while changing operating frequency. The ATU-2 can be mounted inside the Transceiver, while the FC-800 can be installed remotely at the Antenna feedpoint. Each Antenna Tuner is controlled from the front panel of the FT-900,

The MH-31a8J hand microphone is supplied with FT-900, Other accessories include the FP-800 AC Power Supply with Loudspeaker; the SP-6 External Loudspeaker with audio filters and optional LL-5 Phone Patch and the MMB-20 Mobile Mounting Bracket.

Before connecting the power cord, you should read the Installation section carefully, heeding the warnings in that section to avoid damage to the set. After installation, please take time to work through the Operation chapter, referring to the fold-out panel diagrams at the back of the manual as necessary for details. This manual is intended to be read while sitting down in front of the FT-900
so you can try out each control and feature as they are described.
